Product Description
Factory high quality fine mesh nylon filter strainer PA-GG,XX,XXX Nylon Flour Sieve Milling Mesh Size
SPRING can provide you all the specifications and width under good quality and low price. All the Nylon flour mesh XXX series can meet FDA standards.
Detailed Images
1) Series: GG, XX, XXX, FM, PDM, etc.
2) Material: PA6 and PA66
3) FDA certificated
Characters: the mesh with great precision exact and regular square holes, food grade, very good dimensional stability and no any chemicals treatment in the production process
PA/ PET- GG
It mainly used in coarse sieve and peeling. It' s no doubt that nylon GG can replace the metal steel mesh with better elasticity, the abrasion resistance of nylon is better than polyester, and its self-restorability is also much better than steel mesh.
PA-XX
PA-XX is used for soft wheat, biscuit and rye flour
Rough surface
High percentage and open area
Best sieving efficiency
Filteration:
Widely used in areas as filtration and separation industry(Widely used in food filtration and industry filter),the industries of petroleum, chemical, metallurgy, cement, environmental dedusting and mine. Filtration rates can be from 27% to 78%. Such as food industry for milling filtering and flour milling, milling and other grains milling. Like glucose production, milk powder, soybean milk etc.
| Flour Milling Mesh |
| Type | Mesh Count (/cm) | Mesh Count (/inch) | Thread Diameter (/um) | Mesh Opening (um) | Open Area (%) | Thickness (um) |
| PA-12GG | 4.5 | 11.4 | 400 | 1822 | 67 | 760 |
| PA-14GG | 5 | 12.7 | 400 | 1600 | 64 | 770 |
| PA-15GG | 5.5 | 14 | 400 | 1418 | 61 | 780 |
| PA-16GG | 6 | 15.2 | 350 | 1317 | 62 | 665 |
| PA-18GG | 6.5 | 16.5 | 350 | 1188 | 59 | 670 |
| PA-19GG | 7 | 17.8 | 350 | 1079 | 57 | 675 |
| PA-20GG | 7.5 | 19 | 300 | 1033 | 60 | 560 |
| PA-22GG | 8 | 20.3 | 300 | 950 | 58 | 560 |
| PA-24GG | 8.5 | 21.6 | 300 | 876 | 56 | 565 |
| PA-26GG | 9 | 22.9 | 300 | 811 | 54 | 570 |
| PA-27GG | 10 | 25.4 | 250 | 750 | 56 | 475 |
| PA-28GG | 10.5 | 26.7 | 250 | 702 | 54 | 475 |
| PA-30GG | 11 | 28 | 250 | 659 | 53 | 480 |
| PA-31GG | 11.5 | 29.2 | 250 | 620 | 51 | 485 |
| PA-32GG | 11.9 | 30.2 | 250 | 590 | 49 | 490 |
| PA-34GG | 12 | 30.5 | 250 | 583 | 49 | 490 |
| PA-36GG | 12.5 | 31.8 | 250 | 550 | 47 | 490 |
| PA-38GG | 14 | 35.6 | 200 | 514 | 52 | 360 |
| PA-40GG | 14.5 | 36.8 | 200 | 489 | 50 | 365 |
| PA-42GG | 15 | 38.1 | 200 | 466 | 49 | 365 |
| PA-44GG | 16 | 40.6 | 200 | 425 | 46 | 370 |
| PA-45GG | 16.8 | 42.7 | 180 | 400 | 47 | 375 |
| PA-47GG | 17.5 | 44.5 | 180 | 375 | 47 | 375 |
| PA-50GG | 18 | 45.7 | 200 | 355 | 41 | 380 |
| PA-52GG | 20.5 | 52.1 | 150 | 338 | 48 | 270 |
| PA-54GG | 21.5 | 54.6 | 150 | 315 | 46 | 275 |
| PA-58GG | 22 | 55.9 | 150 | 304 | 45 | 275 |
| PA-60GG | 23 | 58.4 | 150 | 285 | 43 | 280 |
| PA-62GG | 23.5 | 59.8 | 150 | 275 | 42 | 285 |
| PA-64GG | 24 | 61 | 150 | 267 | 41 | 285 |
| PA-66GG | 28.5 | 72.4 | 100 | 251 | 51 | 163 |
| PA-68GG | 29 | 73.7 | 100 | 245 | 50 | 165 |
| PA-70GG | 29.5 | 74.9 | 100 | 239 | 48 | 166 |
| PA-72GG | 30.5 | 77.5 | 100 | 227 | 47 | 168 |
| PA-74GG | 32 | 81.3 | 100 | 213 | 46 | 170 |
